| PART NUMBER | 803692775 |
| PART MODEL | A2B-Z / 216661 / DC-12 |
| PART CATALOG | Crane lifting parts |
| APPLICABLE TO | XCMG QY QAY QUY SERIALS CRANE |
| PART NUMBER | 803692775 |
| PART MODEL | A2B-Z / 216661 / DC-12 |
| PART CATALOG | Crane lifting parts |
| APPLICABLE TO | XCMG QY QAY QUY SERIALS CRANE |
| MOQ | 1 PCS |
| STOCK STATUS | In stock |
| GENUINE OR OEM | XCMG genuine spare parts |
| SHIPPING METHOD | Fedex DHL UPS , SEA, AIR.... |
| PAYMENT METHOD | WESTER UNION, T/T, Alipay, WeChat, WISE |
The XCMG Height Limit Switch 803692775 is a genuine HIRSCHMANN anti-two block (A2B) switch designed for XCMG truck cranes and mobile lifting equipment. This crane safety component is used to monitor hook lifting height and prevent dangerous two-block conditions during operation.
Featuring IP67 waterproof protection and IEC60947-5-1 compliance, the A2B-Z DC-12 switch provides reliable performance in demanding construction environments. The product comes with original XCMG packaging and anti-counterfeit label, ensuring authenticity and stable quality.
The anti-two block switch monitors hook movement and helps prevent over-hoisting accidents by sending warning or stop signals when the hook approaches the boom tip.
HIRSCHMANN is widely used in crane safety systems and lifting equipment applications, offering dependable signal transmission and operational reliability.
The IP67 protection level helps protect the switch from dust, moisture, and outdoor environmental conditions.
This product includes:
The XCMG 803692775 height limit switch is available in stock for fast international delivery.
Export Standard Packaging
Worldwide Delivery Support
Yes. This is an original XCMG genuine spare part supplied with original packaging and anti-counterfeit label.
The supplier of this height limit switch is HIRSCHMANN.
The switch is used to prevent hook block collision with the crane boom tip during lifting operations.
Yes. The product is currently in stock and ready for shipment.
The approximate single-piece weight is around 1.5 KG.
We supply original XCMG crane spare parts with stable quality and fast delivery.
Contact us now for:
